Aluminum Zoomable D10U LED Diving Torch 680 Lumens with Aspheric lens

Aluminum Zoomable D10U LED Diving Torch 680 Lumens with Aspheric lens

    • Aluminum Zoomable D10U LED Diving Torch 680 Lumens with Aspheric lens
    • Aluminum Zoomable D10U LED Diving Torch 680 Lumens with Aspheric lens
    • Aluminum Zoomable D10U LED Diving Torch 680 Lumens with Aspheric lens
    • Aluminum Zoomable D10U LED Diving Torch 680 Lumens with Aspheric lens
    • Aluminum Zoomable D10U LED Diving Torch 680 Lumens with Aspheric lens
  • Aluminum Zoomable D10U LED Diving Torch 680 Lumens with Aspheric lens

    Product Details:

    Place of Origin: China
    Brand Name: Archon
    Certification: CE, RoHS
    Model Number: W16U

    Payment & Shipping Terms:

    Minimum Order Quantity: 100 pcs
    Price: USD 20-100
    Packaging Details: 12PCS/CTN 47*37.5*26CM
    Payment Terms: T/T, Western Union
    Supply Ability: 10000 pcs per month
    Contact Now
    Detailed Product Description
    Material: Aircraft Grade Aluminum Surface Treatment: Type III Anodizing
    Color: Black Brightness: Max 680 Lumens
    Waterproof: 60 Meters Underwater

    Aluminum Zoomable W16U LED Diving Torch 680 Lumens with Aspheric lens



    PRODUCT FEATURES

    1. High quality CREE XM-L U2 LED Diving Torch
    2. High tech bright LED with extremely long working life.
    3. Heavy duty & durable,impact resistant
    4. Zoomable light head from 129MM - 144MM
    5. Angle of light beam:10 degree - 55 degree zoomable

    PRODUCT SPECIFICATIONS



    Model W16U zoomable Diving Light/underwater photographing light
    Bulb CREE XM-L U2 LED (Max 680 Lumens)
    Color temperature  6500k
    Three output levels High> Low>Strobe
    Runtime High: 70 min, Low: 320 min, Strobe: 150 min
    Reflector No Reflector
    Lens Aspheric lens
    Body material Durable aircraft-grade aluminum
    Angle of light beam 6°- 68° zoomable
    Surface treatment Premium Type III hard-anodizing
    Color Black
    Battery 18650 Li- ion battery *1
    Circuit Protection With battery over-discharging protection, polarity reversing protection
    Operation voltage 2.8V to 4.5V
    Waterproof 60 meters underwater
    Dimensions 129-144mm (length)*23(dia. of body)*45mm (dia. of head)
    Impact resistance 1.5M
    Weight 190 grams (without battery); 240 grams (with battery)
    Underwater Weight 200 grams (with battery)



    BATTERY INSTALLATION

    1. Remove the tail by turning counter-clockwise.
    2. Remove used batteries and replace with fresh batteries as shown by the polarity stickers.
    3. Mount the tail by turning clockwise. DO NOT ACTIVATE IT YET.



    BATTERY CHARGING

    1. Plug the charger in the wall power socket, the indicator light is green in the free-load status.
    2. Put the battery in the slot of the charger.
    3. The indicator light is red if the battery is not fully charged; it will turn green after fully charged.
    4. Take out the fully charged battery and use them in the diving light.



    ON/OFF



    Turn the tail clockwise until the light activates. DO NOT OVERTIGHTEN.

    To turn the light off, back off the tail counter-clockwise until the light goes off.

    Continue to back off for approximately one full turn to eliminate the possibility of the light activating accidentally in storage. For underwater use, backing off too much will allow water to enter past the o-ring.



    MODES CHANGING



    Successive switch ON-OFF within two seconds to cycle through high, low, strobe.



    Zoom



    Twist the head of the light to zoom the beam.



    SCUBA DIVING APPLICATION



    Check closely for cuts, scratches, or an otherwise damaged o-ring or mating lens surface as this can cause the light to flood under pressure. Remove any salt deposits, sand, dirt, or other foreign matter from the o-ring sealing surfaces.

    KEEP THE THREADS, O-RING GROOVE LUBRICATED WITH SILICONE GREASE.



    CAUTION



    If the light is not to be used for some time, remove the batteries to prevent possible leakage or corrosion. Please remove the batteries during transportation to prevent it from misoperation.



    WARRANTY RETURN POLICY



    Please contact your local distributor or retailer for information on how to handle your warranty items.



    REPLACEMENT PARTS





    CAT#                  DESCRIPTION

    D10U8               O-ring

    D10U9               Lens
