led diving flashlight

Zoomable CREE LED Waterproof Diving Flashlight With Aircraft Grade Aluminum

PRODUCT SPECIFICATIONS

ON/OFF

Turn the tail clockwise until the light activates. DO NOT OVERTIGHTEN.

To turn the light off, back off the tail counter-clockwise until the light goes off.

Continue to back off for approximately one full turn to eliminate the possibility of the light activating accidentally in storage. For underwater use, backing off too much will allow water to enter past the o-ring.

MODES CHANGING

Successive switch ON-OFF within two seconds to cycle through high, low, strobe.

Zoom

Twist the head of the light to zoom the beam.

BATTERY INSTALLATION

1. Remove the tail by turning counter-clockwise.
2. Remove used batteries and replace with fresh batteries as shown by the polarity stickers.
3. Mount the tail by turning clockwise. DO NOT ACTIVATE IT YET.

BATTERY CHARGING

1. Plug the charger in the wall power socket, the indicator light is green in the free-load status.
2. Put the battery in the slot of the charger.
3. The indicator light is red if the battery is not fully charged; it will turn green after fully charged.
4. Take out the fully charged battery and use them in the diving light.

SCUBA DIVING APPLICATION

Check closely for cuts, scratches, or an otherwise damaged o-ring or mating lens surface as this can cause the light to flood under pressure. Remove any salt deposits, sand, dirt, or other foreign matter from the o-ring sealing surfaces.

KEEP THE THREADS, O-RING GROOVE LUBRICATED WITH SILICONE GREASE.

CAUTION

If the light is not to be used for some time, remove the batteries to prevent possible leakage or corrosion. Please remove the batteries during transportation to prevent it from misoperation.

WARRANTY RETURN POLICY

Please contact your local distributor or retailer for information on how to handle your warranty items.

REPLACEMENT PARTS

CAT#                  DESCRIPTION

D10U8               O-ring

D10U9               Lens
