1W - 3W 3535 SMD LED Diode , Cree chip 700mA High Power XP-E UV IR LEDs

1W - 3W 3535 SMD LED Diode , Cree chip 700mA High Power XP-E UV IR LEDs

  • 1W - 3W 3535 SMD LED Diode , Cree chip 700mA High Power XP-E UV IR LEDs
  • 1W - 3W 3535 SMD LED Diode , Cree chip 700mA High Power XP-E UV IR LEDs
1W - 3W 3535 SMD LED Diode , Cree chip 700mA High Power XP-E UV IR LEDs
Product Details:
Place of Origin: CN
Brand Name: Tyanshine
Certification: ISO9001:2008 SGS RoHS
Model Number: TX-3535W3FC120-OGVEND34-03
Payment & Shipping Terms:
Minimum Order Quantity: 1000pcs
Price: Negotiation
Packaging Details: In Reel
Delivery Time: 5-10 days
Payment Terms: ExW, FOB, CIF
Supply Ability: 100000PCS/month
Contact Now
Detailed Product Description
Color: R G B W Y UV IR Power: 1W - 3W
If: 350mA - 700mA
Highlight:

smd led chip

1W - 3W 3535 SMD LED Diode , Cree chip 700mA High Power XP-E UV IR LEDs







Features:

  1. Small size,SMD Package with ceramic substrate
  2. Lower thermal resistance, higher light efficiency
  3. Ceramic base with good heat conductivity to enlarge the lifespan
  4. Packages with Silicon,anti-UV, adaptable for a variety of harsh environments
  5. SMD Components suitable for reflow-solidering,
  6. Multi color options, Red Green Blue White Yellow Ultraviolet(UV) Infrared(IR)

1W - 3W 3535 SMD LED Diode , Cree chip 700mA High Power XP-E UV IR LEDs 0



Specifications:



Code Color Vf (V) If (mA) λd(nm)
CCT(K)		 φv(lm) LES(mm)
TX-3535R3FC120-OGVEND34-03 Red 1.9-2.5 700 618-628nm 50-65lm Φ2.75
TX-3535G3FC120-OGVEND34-03 Green 2.8-3.6 700 520-530nm 80-110lm
TX-3535B3FC120-OGVEND34-03 Blue 2.8-3.6 700 456-468nm 19-31lm
TX-3535W3FC120-OGVEND34-A03 White 2.8-3.6 700 ≥7000 K 94-139lm
TX-3535Y3FC120-OGVCND34-01 Yellow 2.0-3.0 700 585-595nm 60-75lm
TX-3535P3FC120-OGVEZA72-01 Ultraviolet UV 3.0-3.6 700 380-400nm 1-1.5lm
TX-3535IR3FC120-OGVCND34-03

Infrared

IR

 1.7-1.9V 350 850-858nm 260-320mW





Package Dimensions:



1W - 3W 3535 SMD LED Diode , Cree chip 700mA High Power XP-E UV IR LEDs 1



Applications:



Portable LED Flashlight

Automobile illumination
Architectural lighting

Landscape lighting

LED Street Light, LED High Bay Lights, LED Tunnel Lights

Secruity application CCTV products
