1. Features
• Aircraft grade aluminum body with hard anodized finish, water resistant and shock resistant
• Li-ion battery, self-protection from over charge and over discharge
• Integrated CMOS video camera
• DVR flashlight with display screen
• Spotlight and floodlight for lighting, or lighting conditions for high quality pictures and video
• Independent video, taking photos and lighting On/Off switch
• Big storage capacity for video and photos
• Downloads directly to your computer via USB cable (included) or copy it from TF card directly
2. Specification
|
No.
|
item
|
parameter
|
unit
|
|
1
|
Rated voltage
|
3.7
|
V
|
|
2
|
Reted capacity
|
2.2
|
Ah
|
|
3
|
Light source
(LED)
|
Rated power
|
2 / 1
|
W
|
|
Lifetime
|
100.000
|
h
|
|
Color temp.
|
5500
|
K
|
|
4
|
LED Continuous working time
|
≥7
|
h
|
|
5
|
Charging time
|
≤5
|
|
6
|
Video working time
|
With strong light
|
≥2.5
|
|
No light
|
≥4
|
|
7
|
View Angel
|
100
|
degree
|
|
8
|
Camera pixel
|
5
|
million
|
|
9
|
Image resolution
|
4000x3000,2562x1944,1920x1080, 1280x720,848x480 (alternative)
|
|
10
|
video resolution
|
1920x1080, 1280x720, 840 x 480 (alternative)
|
|
11
|
Storage Medium
|
4/ 8/ 16/ 32
|
G
|
|
12
|
Audio/video size
|
35MB--100MB
|
MB/ minute
|
|
13
|
Video format
|
AVI
|
|
14
|
Battery circular life
|
1000
|
circle
|
|
15
|
Dimension:
|
Φ65×230
|
mm
|
|
16
|
Weight(About)
|
1000
|
g
|
|
17
|
Operating Temperature
|
-10~+40
|
degree
|
|
18
|
Operation Humidity
|
15~85%
|
RH
|
|
19
|
IP Grade
|
IP66
|
3. Product details:
Button function
4. Usage Guide
-
Taking photo:
If you want to take photos, pressing the power botton for 2 seconds to switch on the power, then
press the photograph button, the indicator is green which means the photo is took and saved. Then you can press it for 2 seconds to see the photo you took.
-
Taking video:
If you want to take videos, pressing the power botton for 2 seconds to switch on the power, then press the DV button. The indicator is flashing green when the camera is working, please press it again if you want to finish taking video.Then you can press it for 2 seconds to watch the video you took.
-
Pixel settings:
Press the OK button for 2 seconds to enter the menu mode, then you can set the photo and video pixels. Press it again to exit the menu mode.
-
Charging:
You don’t need to take the battery out for charging. Just plug the charger terminal into the port of the flashlight end cap then connect to the power. The indicator on the charger would light on when charging and would turn off when charging is finished.
5. Transfer the files in the memory cards
Screw out the flashlight tail section, then connect the flashlight and your computer by the USB cable or you can take off the memory card and read it by your computer directly. Then you can move or copy the files in the card to anywhere you want.
-
Notes
1. The USB of flashlight support WIN7, and XP system. When you connect the USB, please
press the power button, then it will be able to connect the memory card.
2. If the red light on, means there’s no TF card. When the red light flashes slowly means that
the TF card is full and need to be emptied. But if the red light flashing rapidly, it shows that
there’s no enough power.
3. When long-term storage is needed, charging should be done within two months.
