Scuba Diving Lamp Underwater Photographing Video Lights LED Dive Torches

Scuba Diving Lamp Underwater Photographing Video Lights LED Dive Torches

    • Scuba Diving Lamp Underwater Photographing Video Lights LED Dive Torches
    • Scuba Diving Lamp Underwater Photographing Video Lights LED Dive Torches
    • Scuba Diving Lamp Underwater Photographing Video Lights LED Dive Torches
    • Scuba Diving Lamp Underwater Photographing Video Lights LED Dive Torches
  • Scuba Diving Lamp Underwater Photographing Video Lights LED Dive Torches

    Product Details:

    Place of Origin: Guangdong,China
    Brand Name: Archon
    Certification: CE,RoHS
    Model Number: W17V

    Payment & Shipping Terms:

    Minimum Order Quantity: 100pcs
    Price: USD 20-100
    Packaging Details: EVA Box.12PCS/CTN.Carton Size Dimension:47*37.5*26CM
    Payment Terms: T/T, Western Union
    Supply Ability: 10000 pcs per month
    Contact Now
    Detailed Product Description
    Material: Aluminum Alloy Max Power: 860 Lumens
    Working Voltage: 3V To 6V Surface Treatment: Premium Type III Hard-Anodizing
    Underwater Weight: 95 Grams (with Battery) Impact Resistance: 1.5M
    Waterproof: Underwater 100Meters

    Scuba Diving Lamp Underwater Photographing Video Lights LED Dive Torches



    SCUBA DIVING APPLICATION



    Check closely for cuts, scratches, or an otherwise damaged o-ring or mating lens surface as this can cause the light to flood under pressure. Remove any salt deposits, sand, dirt, or other foreign matter from the o-ring sealing surfaces.

    KEEP THE THREADS, O-RING GROOVE LUBRICATED WITH SILICONE GREASE.



    PRODUCT SPECIFICATIONS:



    Model W17V Underwater Photographing Video Lights
    Bulb CREE XM-L LED (Max 680 Lumens)
    Color temperature  5000k
    Three output levels High> Low>Strobe
    Runtime 70 min, Low: 320 min, Strobe: 150 min
    Reflector No Reflector
    Lens Aspheric lens
    Body material Durable aircraft-grade aluminum
    Angle of light beam 110 degree
    Surface treatment Premium Type III hard-anodizing
    Color Black
    Battery 18650 Li- ion battery *1
    Circuit Protection With battery over-discharging protection, polarity reversing protection
    Operation voltage 3V to 6V
    Waterproof 100 meters underwater
    Dimensions 125mm (length)*24(dia. of body)*40mm (dia. of head)
    Impact resistance 1.5M
    Weight 190 grams (without battery)
    Underwater Weight  95 grams (with battery)



    Operation Instruction



    Successive switching ON-OFF within two seconds to cycle through high, low, strobe



    ON/OFF



    When the light is off,turn the lamp tail clockwise until it activates.DO NOT OVERTIGHTEN.To turn the light off,back off the lamp tail counter-clockwise 90 degree or less than one full turn.For underwater use,backing off more than one full turn will probably cause flood.



    Continue to back off for approximately one full turn to elimate the possibility of the light activating accidently in storage.



    LOW BATTERY WARNING



    The light flashes 3 times if the battery voltage is less than 10% ;it repeats after 5seconds,and then switches to low brightness.The light switches off when the voltage is less than 5%.



    CAUTION



    If the light is not to be used for some time, remove the batteries to prevent possible leakage or corrosion. Please remove the batteries during transportation to prevent it from misoperation.
